Clutch Kit - Xtreme Performance Heavy Duty Sprung Ceramic Incl Flywheel 992Nm 1400kg LANCER EVO IV (CN9A)

1.715,62
(Price excluding VAT): 1.417,87
Stock:
0 Items
Item No.:
KMI24522-1B

Clutch Kit - Xtreme Performance Heavy Duty Sprung Ceramic Incl Flywheel 992Nm 1400kg LANCER EVO IV (CN9A)

Contact us for installation, availability or other possible clutch models.
Xtreme Performance - sprung ceramic kit /-1B
Recommended for: Motorsport Applications

These kits are available with sprung ceramic friction discs and are designed for motorsport applications where higher heat and torque capacity is required. These can also be used in some road applications.

Specifications:
  • Torque capacity 992Nm
  • Clamp load 1400kg Increased over standard
  • Sprung Ceramic Friction Disc
  • Heavy Duty Pressure Plate
  • Kit contains everything you need for a successful installation + accessories

The sprung ceramic range of kits have been developed for motorsport applications where a higher heat and torque capacity is required. These discs utilise a sprung hub that helps to reduce shock loading and are commonly used in track cars that retain the factory transmission.

Xtreme Performance
At Xtreme Clutch, we strive to offer a variety of clutch options for each vehicle to ensure a clutch solution is available for every vehicle application. Whether you are modifying a road vehicle or building a race car from scratch, we have the clutch solution for you. Our upgrades are divided into different stages depending on the friction disc material and the number of friction discs.

What's in the Box?

Xtreme Performance upgrade kits are available with everything you need for a successful installation + accessories you may want to upgrade or replace while the gearbox is out of the vehicle.

Xtreme Performance

Clutch Disc Diameter (mm): 240

Clutch Disc Spline Count: 23

Clutch Disc Spline Diameter (mm): 26.2

Torque (Nm): 1000

Flywheel Step: 0

Design: Single Plate

Stage: Stage 2

Tech Bulletins:

Clamp Load: 1400Kg

Recommended for: Track - Stage 2

Ring Gear Tooth count:

Additional information:

Fits:

- MITSUBISHI/LANCER/EVO IV (CN9A)/1996.08-1997.12/4G63 Turbo 1997 Petrol 206 kW 280 BHP (1996.08 - 1997.12) ,

- MITSUBISHI/LANCER/EVO V - RS450 Ralliart (CP9A)/1998.01-1998.06/4G63 Turbo 1997 Petrol 336 kW 456 BHP (1998.01 - 1998.06) ,

- MITSUBISHI/LANCER/EVO VI (CP9A)/1999.01-2001.02/4G63 Turbo 1997 Petrol 207 kW 281 BHP (1999.01 - 2001.02) ,
