Differential overhaul 168L (4-cyl models)

Core charge

Achteraf (geen borg)
Achteraf (met borg) (+ €300,00)
Vooraf

Mounting it on the car

Ratio

€725,00

Price excluding VAT: €599,17

Stock:

1 Items

Item No.:

168L-rev

Differential overhaul 168L (4-cyl models)

Voorraadstatus is niet leidend voor dit specifieke artikel. Graag contact opnemen m.b.t. de levertijd.

More Hardeman Rebuilds | More Driveline and differential

In particular: E87, E90, E91, E92, E93 (4 cylinder models, heavier models also possible on request)

If you are bothered by noises such as singing/rattling from the differential, one of the bearings is most likely worn out. This is the weak point of this kind of differentials. We can completely overhaul your differential, so new bearings, seals, cups, etc. In this way you do not have to worry about the differential breaking again, as will happen with many used or not completely overhauled ones. The differential is blasted and painted as standard so that it is delivered as shown in the example photo.

The differential is covered by a 2-year warranty after revision.

You can also contact us for the revision of other types of differentials. We have extensive experience in racing and rally sports, where we often drive with high power, so we know the weak points of a differential like no other.

The price applies with return of your own (defective) differential. For certain models we have an exchange copy available, inquire about the possibilities.

https://hardemanmotorsport.nl/revisie/

Possibility of revision: (actually all BMW but among others:)

1'E81
116d (N47)
118d (N47)
120d (N47)
123d (N47S)
130i (N52N)
1'E87
120d (M47N2)
130i (N52)
1' E87 LCI
116d (N47)
118d (N47)
120d (N47)
123d (N47S)
130i (N52N)
1'E82
120d (N47)
123d (N47S)
125i (N52N)
128i (N52N)
128i (N51)
135i (N54)
1'E88
118d (N47)
120d (N47)
123d (N47S)
125i (N52N)
128i (N51)
135i (N54)
3'E90
318d (M47N2)
318d (N47)
320d (M47N2)
320d (N47)
325d (M57N2)
325i (N52)
325i (N52N)
325i (N53)
325xi (N52)
325xi (N52N)
325xi (N53)
328i (N51)
328i (N52N)
328xi (N51)
328xi (N52N)
330i (N52)
330i (N52N)
330i (N53)
330xd (M57N2)
330xi (N52)
330xi (N53)
335i (N54)
335xi (N54)
3' E90 LCI
318d (N47)
320d (N47)
320xd (N47)
325d (M57N2)
325i (N52N)
325i (N53)
325xi (N52N)
325xi (N53)
328i (N51)
328i (N52N)
328xi (N51)
328xi (N52N)
330i (N52N)
330i (N53)
330xd (N57)
330xi (N53)
335i (N54)
335xi (N54)
3'E91
318d (M47N2)
318d (N47)
320d (M47N2)
320d (N47)
325d (M57N2)
325i (N52)
325i (N52N)
325i (N53)
325xi (N52)
325xi (N52N)
325xi (N53)
328i (N52N)
328xi (N52N)
330i (N52)
330i (N52N)
330i (N53)
330xd (M57N2)
330xi (N52)
330xi (N53)
335i (N54)
335xi (N54)
3' E91 LCI
318d (N47)
320d (N47)
320xd (N47)
325d (M57N2)
325i (N52N)
325i (N53)
325xi (N52N)
325xi (N53)
328i (N52N)
328xi (N52N)
330i (N52N)
330i (N53)
330xd (N57)
330xi (N53)
335i (N54)
335xi (N54)
3'E92
320d (N47)
320xd (N47)
325d (M57N2)
325i (N52N)
325i (N53)
325xi (N52N)
325xi (N53)
328i (N52N)
328i (N51)
328xi (N51)
328xi (N52N)
330i (N52N)
330i (N53)
330xd (M57N2)
330xd (N57)
330xi (N52N)
330xi (N53)
335i (N54)
335xi (N54)
3'E93
320d (N47)
325d (M57N2)
325i (N52N)
325i (N53)
328i (N51)
328i (N52N)
330i (N52N)
330i (N53)
335i (N54)

33107564878	24,926 kg	I=41:10=4,10	Part 33107564878 was found on the following vehicles: 3' E90 (09/2005 - 08/2006)	3-1-2006	33107564879
33107555315	24,926 kg	I=4,10	Part 33107555315 was found on the following vehicles: 1' E81 (03/2007 - 12/2011) 1' E87 LCI (02/2006 - 06/2011) 1' E88 (11/2006 - 10/2013) 3' E90 (02/2007 - 08/2008) 3' E90 LCI (05/2008 - 10/2011) 3' E93 (09/2005 - 02/2010) 3' E93 LCI (09/2009 - 10/2013)	3-1-2007	33107555316
33107591022	24,926 kg	I=3,15	Part 33107591022 was found on the following vehicles: 1' E88 (03/2008 - 10/2013) 3' E90 (02/2004 - 08/2008) 3' E90 LCI (07/2007 - 12/2011) 3' E91 (02/2004 - 08/2008) 3' E91 LCI (03/2008 - 05/2012) 3' E92 (05/2005 - 02/2010) 3' E92 LCI (09/2009 - 06/2013) 3' E93 (09/2005 - 02/2010) 3' E93 LCI (09/2009 - 09/2013) X1 E84 (06/2009 - 06/2015)	9-1-2008	33107566177
33107564879	25,160 kg	I=4,10	Part 33107564879 was found on the following vehicles: 3' E90 (09/2005 - 08/2006)	3-1-2006	33107564878
33107519925	25,330 kg	I=40:11=3,64	Part 33107519925 was found on the following vehicles: 1' E81 (09/2006 - 11/2011) 1' E87 (03/2003 - 02/2007) 1' E87 LCI (09/2006 - 06/2011) 1' E82 (06/2009 - 10/2013) 3' E90 (08/2004 - 09/2008) 3' E90 LCI (07/2007 - 12/2011) 3' E91 (02/2007 - 08/2008) 3' E91 LCI (03/2008 - 05/2012) 3' E92 (09/2006 - 02/2010) 3' E92 LCI (11/2008 - 06/2013) 3' E93 (09/2005 - 02/2010) 3' E93 LCI (09/2009 - 10/2013)	6-1-2004	33107519926
33107519926	25,330 kg	I=3,64	Part 33107519926 was found on the following vehicles: 1' E81 (09/2006 - 11/2011) 1' E87 (03/2003 - 02/2007) 1' E87 LCI (09/2006 - 06/2011) 1' E82 (06/2009 - 10/2013) 3' E90 (08/2004 - 09/2008) 3' E90 LCI (07/2007 - 12/2011) 3' E91 (02/2007 - 08/2008) 3' E91 LCI (03/2008 - 05/2012) 3' E92 (09/2006 - 02/2010) 3' E92 LCI (11/2008 - 06/2013) 3' E93 (09/2005 - 02/2010) 3' E93 LCI (09/2009 - 10/2013)	6-1-2004	33107519925
33107524319	25,450 kg	I=44:13=3,38	Part 33107524319 was found on the following vehicles: 1' E81 (02/2006 - 12/2011) 1' E87 (07/2004 - 02/2007) 1' E87 LCI (02/2006 - 06/2011) 3' E90 (02/2004 - 08/2008) 3' E90 LCI (05/2008 - 10/2011) 3' E91 (03/2004 - 08/2008) 3' E91 LCI (05/2008 - 05/2012) 3' E92 LCI (10/2009 - 06/2013) 3' E93 (03/2007 - 12/2009) 3' E93 LCI (02/2010 - 04/2012)	12-1-2004	33107524320
33107524324	25,450 kg	I=3,73	Part 33107524324 was found on the following vehicles: 1' E81 (09/2006 - 12/2011) 1' E87 (03/2003 - 02/2007) 1' E87 LCI (02/2006 - 06/2011) 1' E88 (11/2006 - 10/2013) 1' E82 (06/2009 - 09/2013) 3' E90 (08/2004 - 09/2008) 3' E90 LCI (05/2008 - 12/2011) 3' E91 (03/2005 - 07/2008) 3' E91 LCI (06/2008 - 05/2012) 3' E92 (04/2006 - 11/2009) 3' E92 LCI (11/2009 - 02/2012) X1 E84 (09/2008 - 06/2015)	9-1-2005
33107524322	25,480 kg	I=3,45	Part 33107524322 was found on the following vehicles: 1' E81 (09/2006 - 10/2011) 1' E87 (03/2003 - 02/2007) 1' E88 (09/2007 - 10/2013) 3' E90 (03/2007 - 08/2008) 3' E90 LCI (03/2008 - 12/2011) 3' E91 (02/2007 - 08/2008) 3' E91 LCI (07/2007 - 05/2012) 3' E93 LCI (10/2009 - 09/2013)	9-1-2005	33107539776
33107524325	25,480 kg	I=43:11=3,91	Part 33107524325 was found on the following vehicles: 1' E81 (02/2006 - 12/2011) 1' E87 (03/2003 - 02/2007) 1' E87 LCI (02/2006 - 06/2011) 1' E88 (09/2007 - 10/2013) 1' E82 (06/2009 - 10/2013) 3' E90 (02/2004 - 09/2008) 3' E90 LCI (07/2007 - 12/2011) 3' E91 (03/2004 - 08/2008) 3' E91 LCI (07/2007 - 05/2012) 3' E92 (09/2006 - 02/2010) 3' E92 LCI (11/2008 - 06/2013) 3' E93 (03/2007 - 12/2009) 3' E93 LCI (02/2010 - 04/2012)	6-1-2004	33107524326
33107524318	25,790 kg	I=3,23	Part 33107524318 was found on the following vehicles: 1' E87 (07/2004 - 02/2007) 3' E90 (08/2004 - 09/2008) 3' E90 LCI (05/2008 - 12/2011) 3' E91 (03/2005 - 07/2008) 3' E91 LCI (06/2008 - 05/2012) 3' E92 (04/2006 - 11/2009) 3' E92 LCI (11/2009 - 02/2012)	12-1-2004	33107524317
33107539776	25,480 kg	I=3,38	Part 33107539776 was found on the following vehicles: 1' E87 (03/2003 - 02/2007)	6-1-2004	33107524322 33107524319, 33107524320
33107556795	26,000 kg	I=2,47	Part 33107556795 was found on the following vehicles: 1' E87 (02/2003 - 02/2007)	06/16/2005	33107542092
33107592932	26,000 kg	I=4,44	BMW Xi E83		33107592932 33107592933
