-2E

The Xtreme 184mm Race Clutch is an economically priced solution for those wanting a strong Race clutch without having to compromise on quality. The Race Clutch is a lightweight design for when every second counts.

??	Ø184mm Light Diaphragm (2.6mm)	Ø184mm Heavy Diaphragm (2.8mm)
Clamping Force	950kg	1080kg
Torque Rating	1060Nm	1210Nm
Bearing Contact Diameter	44-52mm	44-52mm
Bearing Load (@ 48mm)	210kg	260kg
Release Travel Required	5mm	5mm
Assembly Mass (without flywheel)	4.45kg	4.45kg
Disc Set Static Mass	1.1kg
Friction Thickness New	6.35mm (0.250")	6.35mm (0.250")
Friction Thickness Worn	5.97mm (0.235")	5.97mm (0.235")

Product Features:

Push type billet alloy cover
4140 Chromoly pressure plate
Hardened steel wear posts
High and low ratio pressure plate options
Low inertia
Serviceable components
SFI certified design

Xtreme Performance - 184mm Rigid Ceramic Twin Plate Clutch Kit Incl Flywheel & CSC 1220Nm YARIS 1.6 GR 4WD (GXPA16)

-2E

The Xtreme 184mm Race Clutch is an economically priced solution for those wanting a strong Race clutch without having to compromise on quality. The Race Clutch is a lightweight design for when every second counts.

Product Features:
